Features
냉동고가 결합되어 있는 제약 냉장고
Safe storage
- Microprocessor control system provides accurate temperature.
- Fan-forced air circulation system (refrigerator) offers fast recovery of temperature and better uniformity.
- Unique cycle defrost system prevents temperature rising by shorter defrost cycles which activate after each compressor cycle.
- Various safety systems such as high/low temperature audible and visual alarms, remote alarm, door ajar alarm and keyed door locks.
- MPR-414FS has no glass on the door to keep contents unseen.
Usability
- One unit with dual temperature zone needs only minimal installation space.
- Four-door design reduces air loss during door opening and makes efficient use of space in front of unit. (MPR-414F/FS)
- Triple-pane (MPR-414F) or double-pane (MPR-215F) windows with heat reflection film reduce condensation.
- Zero adjustment through control panel and optional recorder provide easier validation service.
Quiet operation
- Two specially designed compressors offer quiet operation.
Features
- One unit dual temperature zone (Refrigirator with Freezer)
- Superior cooling performance
- Quiet operation
- Various alarm and safety functions
Specfications
| Product Series Name | Pharmaceutical Refrigerators |
|---|---|
| Model | MPR−215F |
| External Dimensions | 540 x 557 x (45) * x 1794 (mm) / 21.3 x 21.9 x (1.8) * x 70.6 (inch) * projection |
| Internal Dimensions | 455 x 466 x 917 (mm) / 17.9 x 18.3 x 36.1 (inch) |
| Effective Capacity | 176 liters (6.2 cu.ft.) |
| External Cabinet | Galvanized steel with baked on finish |
| Internal Cabinet | Styrene resin |
| Insulation | Rigid polyurethane foamed in place |
| Shelves | 3 |
| kg/Shelf | 20 kg / shelf |
| Access port | ø 30 mm (left) |
| Casters | 4 casters with 2 adjustable leveling feet |
| Cooling method | Fan-forced air circulation |
| Compressor | 55 W |
| Refrigerant | HFC |
| Temperature range | + 2 °C to + 14 °C (Ambient temp. : 30 °C) |
| Temperature control | Microprocessor control |
| Net weight | 86 kg (190 lbs.) |
| Freezer : Internal Dimensions | 420 x 342 x 267 (mm) / 16.5 x 13.5 x 10.5 (inch) |
| Freezer : Effective Capacity | 39 liters (1.4 cu.ft.) |
| Freezer : External Cabinet | Galvanized steel with baked on finish |
| Freezer : Internal Cabinet | Colored aluminum plate |
| Freezer : Outer Door | - |
| Freezer : Insulation | Rigid polyurethane foamed in place |
| Freezer : Shelves | 1 |
| Freezer : Access Port | ø 30 mm (left) |
| Freezer : Lighting / Casters | 4 casters with 2 adjustable leveling feet |
| Freezer : Cooling Method | Direct cooling |
| Freezer : Compressor | 55 W |
| Freezer : Refrigerant | HFC |
| Freezer : Temperature Control Range | Microprocessor control |
| Freezer : Alarms | - |
- *Cooling performance is indicated by the temperature reached at the center of the freezer (at ambient temperature of 30°C with no load). In order to use the freezer at a stable temperature for a long time, it is recommended that the temperature be set to at least 5°C higher than the indicated lowest temperature.
In addition, depending on the usage conditions, it may not be possible to reach the indicated lowest temperature. - Caution: Panasonic guarantees the product under certain warranty conditions. Panasonic in no way shall be responsible for any loss of content or damage to content.
- Appearance and specifications are subject to change without notice.
- *1 Exterior dimensions of main cabinet only - see dimension drawings showing handles and other external projections.
